What is Compaction Equipment?

Most construction sites and road construction need stable ground to do their work on. The soil needs to be compressed so there are not any pockets of air underground that can disrupt the process. Compaction equipment rearranges particles in the soil or any soft ground to decrease voids and increase density.

They provide the surface with sufficient load-bearing strength, with their drum or plate, to crush and flatten the soil. The most common type of project that uses compaction equipment involves construction project, particularly roadwork. Without compaction equipment, roads would have irregular and extensive surface wear, making it dangerous to travel. Compaction equipment is also working well to create and compact foundation ground.

Typically, we can categorize Compaction Equipment into light compaction equipment and heavy compaction equipment

Light Compaction Equipment

There are 3 common types of light compaction equipment in the market.

1. Rammer

Rammers is the smallest manual compactor and work great when compacting cohesive soils because of the small size of the plate. It can fit into narrow spaces such as trenches and tight spots where compactors are not as easy to manoeuvre. The smaller plate size allows for more focused and direct compaction, which comes in handy on soils that require more force to properly compact. Instead of using vibratory force, its use impact force for compaction.

2. Plate Compactor

Plate Compactor are ideal when working with granular soils because they use vibrations to help settle the soil as it compacts and with its large vibrating baseplate and is suited for creating a level grade. A vibratory plate compactor is used for the compaction of different types of soils in narrow & restricted areas where it is not possible to use large equipment. These walk-behind machines are used for preparing car parks, footpaths, foundations, sub-bases, trenches and paving, especially in confined areas where turning a vehicle is difficult.

3. Walk Behind Roller

As known by name, walk behind roller mean an operator is required to walk behind and control the roller to work. This compactor is bigger than the other light compactor and much smaller than those heavy compactor rollers. Hence, it provides excellent performance on medium compacting jobs on granular materials, soils and asphalt. The equipment also offers great visibility to the operator at any angle which allows precise work near walls and sidewalks because of its compact design.

Heavy Compaction Equipment

There are 4 common types of heavy compaction equipment in the market.

1. Smooth Wheeled Roller

This roller is also known as a static smooth wheeled roller. This roller is commonly used for finishing the upper surface of the soil, but not used for the compaction of uniform sand. This type of roller equipped with a large steel drum at the front and one or two wheels or drums at the rear. They named tandem roller (one wheel at the rear) and three-wheeled roller (two wheels at the rear).

2. Vibratory Roller

The major difference with smooth wheel roller is vibratory roller fitted with vibrating component, vibrate by the rotation of an eccentric shaft inside. This roller is commonly used for compacting granular base courses and sometimes for asphalt and are useful for compacting to greater depths.

3. Sheepsfoot Roller

This roller also known as pad foot roller and generally used for compacting fine-grained soil such as heavy clays and silty clay in road construction work. This type of roller consists of a steel drum on which round or rectangular protrusions are known as lugs or feet is fixed.

4. Pneumatic Tyre Roller

This roller also known as rubber tyres roller and generally used for compaction of uniform coarse soil and rocks as well as in pavement sub-grade works both earthwork and bituminous work. The pneumatic roller consists of wheels on both axles. These wheels are staggered for the compaction of soil layers with uniform pressure throughout the width of the roller. The factors which affect the degree of compaction are tyre inflation pressure and the area of the contact.

Antbuildz.com offers a wide range of Compaction Equipment brand either compaction roller or plate compactor and models for rental in Singapore with a wide range of operation specification range.

There are many well-known Compaction Equipment brands available but not limited to as below:

Bomag
Bobcat
Caterpillar
Case
Dynapac
Sakai
Wacker Neuson
JCB
Mecalac
Kanto
XCMG
Hamm

Common FAQs

1. What is the factors that I need to consider when renting compaction equipment?

First, you would need to consider the working condition and decide is it light or heavy compaction that equipment that you need. Secondly, you need to what type of soil that you are compacting, then you can decide if you need vibratory compaction equipment (such as compaction roller and plate compactor) or impact force compaction equipment (rammer).

2. What is the minimum and maximum operating weight of compaction equipment available?

For light compaction equipment such as rammer, plate compactor, and walk behind roller, usually, the range can be from less than 100kg up to 1 ton.

For heavy compaction equipment such as compaction roller. the operating weight can easily range from 1 ton up to 20 ton.

3. Do the rental include of operator?

The common practice of compaction equipment rental in Singapore is excluded from the operator. However, if you need operator supply, you may talk to our team to provide you.

4. What is the rental price of compaction equipment?

The monthly rental rate of light compaction equipment can be range up to $500 per month for 1T walk-behind compaction roller exclude of delivery charges.

The monthly rental rate of heavy compaction equipment can be range up to $2000 per month for heavy compaction roller exclude of delivery charges.

You can also rent for a short duration be it daily or weekly via antbuildz.com.

5. Can I rent the compaction roller as short as a one-day rental?

Yes, antbuildz.com is allowed you to rent excavators for as short as one day up to months as you require.

6. Is the rental covered with All Risk Insurance?

Yes, be it one-day rental or months rental, every rental you made across antbuildz.com will be protected with Antbuildz Machinery All Risk up to S$15,000 to make your rentals safer than ever. Only antbuildz.com covers you with All Risk Insurance in entire Singapore, and it's FREE!
